Roadster Fuse Layout

Mod Description
Mod Details
PremiumNo Difficulty Mod ID469 Creditsmart For452 Roadster Linkhttps://www.evilution.co.uk/mod/roadster-fuse-layout.htm Copy to Clipboard



No   Amp. Colour
1 Starter 25 A Neutral
2 Windscreen wipers, washer pump 20 A Yellow
3 Heater blower, seat heater 20 A Yellow
4 Power windows, l. & r. 30 A Green
5 Light switch 7.5 A Brown
6 Front parking lights, tail lights, instrument cluster lights 7.5 A Brown
7 Parking lights/tail lights, l. 7.5 A Brown
8 Coil packs 20 A Yellow
9 ECU, engine connector, secondary air injection, charcoal filter valve 10 A Red
10 Injectors 15 A Blue
11 Instrument cluster, Key antenna, trip computer, OBD 7.5 A Brown
12 Radio CD, interior light 15 A Blue
13 Fog lamps 15 A Blue
14 esp valves 25 A Neutral
15 A/C compressor. chargecooler pump or intercooler fan 15 A Blue
16 Electric fuel pump 10 A Red
17 Rear window wiper (unused) 15 A Blue
18 Airbag triggering device, esp 7.5 A Brown
19 Mirror adjustment, soft top switch 7.5 A Brown
20 Radio, CD, instrument cluster, tachometer, OBD, backup lamp, PAS controller, fog lamp relay. 15 A Blue
21 Power socket / Cigarette lighter socket 15 A Blue
22 Low beam light, r. 7.5 A Brown
23 Low beam light, l. 7.5 A Brown
24 High beam light, r. 7.5 A Brown
25 High beam light, l./combined light 7.5 A Brown
26 Brake light 15 A Blue
27 Engine control unit 7.5 A Brown
28 Rear window heater, wing mirror heaters 30 A Green
29 Soft top motor 25 A Neutral
30 Relay for automated gearbox, SE Drive unit 40 A Orange
31 Horn, central locking, rear lid remote unlocking 30 A Green
32 Secondary air injection pump 30 A Green
33 Ignition 50 A Red
34 esp pump 50 A Red
35 Power steering 30 A Green
36 (R1) Backup fuse 15 – switched live _ _
37 (R2) Backup fuse 15 – switched live _ _
38 (R3) Backup fuse 15 – switched live _ _
39 (R4) Backup fuse 15 – switched live _ _
40 (R5) Backup fuse 30 – permanent live _ _
41 (R6) Backup fuse 30 – permanent live _ _
42 (R7) Backup fuse 30 – permanent live _ _
43 (R8) Backup fuse 30 – permanent live _ _
44 (R9) Seat heaters – permanent live 25 A _
